Q-SYS unD6IO-BT Dante™ Networked Audio Wall Plate (Attero Tech)
Bluetooth media streaming: The unD6IO-BT wall plate is compatible with most smartphones, Apple iPads, and Android tablets, providing Bluetooth media streaming and call bridging for a wide variety of commercial applications. Control plugin allows for control and monitoring of the unD6IO-BT via native Q-SYS touch screen controller.
Bluetooth call bridging: Provides simple bridging of far-end meeting participants for on-the-fly meeting productivity and backup conference connectivity.
Q-SYS integration: A Q-SYS Extension is available for the unD6IO-BT in Q-SYS Designer Asset Manager, which enables control and monitoring via native Q-SYS touch screen controllers.
Out of the box: In addition to Bluetooth media streaming, the unD6IO-BT also features a two RCA line level inputs, one 3.5 mm line level input and one 3.5 mm line level output – providing connectivity flexibility for any application type. The input configuration can be modified within Q-SYS or Attero Tech unIFY Control Panel software.
| Details | unD6IO-BT |
| Bluetooth® profile | A2DP - Stereo audio is streamed from a Bluetooth® device and onto the Dante network. HFP (Hands Free Profile) - duplex pairing to a cell phone for call bridging |
| Bluetooth® range | 10 m (30 ft) minimum. Typical range is 15 - 23 m (50 - 75 ft) |
| RCA and 3.5 mm input | RF filtered line level, input source software selectable |
| Maximum input levels (3.5 mm / RCA): | +12 dBu |
| Output volume range | 0 dB to -60 dB in 1 dB steps, "software selectable" |
| 3.5 mm output | RF filtered line level |
| Maximum output level (3.5 mm) | +12 dBu |
| Product dimensions (H × W × D) | 3.54 x 4.2 x 1.88 inches (89.91 x 106.68 x 47.752 mm) Decora wall plate (2-gang): 4.87 x 4.94 x 0.08 in (123.7 x 125.48 x 2.03 mm) |
| Shipping dimensions (H × W × D) | 6 x 6 x 4 inches (152.4 x 152.4 x 101.6 mm) |
| Shipping weight | 1.0 lb (0.45 kg) |
The QSC AcousticPerformanceTM AP-5122 is a professional, two-way, full-range loudspeaker ideal for a variety of installed sound reinforcement applications requiring higher SPL output and a clean appearance. The AP-5122 uses a high power-capacity, 76mm (3-inch) diaphragm compression driver and combines it with a 305mm (12-inch) woofer to deliver exceptional
full bandwidth reproduction.
6.5" small format, surface mount loudspeaker
- 4.5-inch weather treated woofer; 0.75-inch silk dome tweeter
- 120° conical DMT™ coverage
- 30 watt low-saturation and low-loss 70/100V transformer with 8Ω bypass
- Maximum peak SPL 110 dB (8 ohm bypass)
- Directivity Matched Transition® (DMT) ensures smooth, uniform frequency response over the coverage area
- X-Mount™ system enables the loudspeaker to be easily installed and deployed at a variety of angles with no slippage over time
- Advanced Intrinsic Correction™ voicings available via Q-SYS™
- Lightweight ABS enclosures offer long-term durability and lasting good looks
- Sealed input panel cover and powder coated aluminum grilles for added weather resistance
- Meets IEC60529 IP-54 for dust and splash resistance
- Available in black (RAL 9011) or white (RAL 9010)
- Complete EASE, CF2, CAD, and BIM information available online
The AcousticDesign™ AD-P6T is a 6.5-inch two-way pendant-mount loudspeaker ideally suited for a wide variety of foreground and background sound reinforcement applications which utilize 70/100V or 16Ω bypass configurations.
Soft, padded cover made with weather-resistant, heavy-duty Nylon/Cordura® material for KS112.
